ADDA – 60x60x20 DC Fan Series | FONTEK

Full Range of Delta Cooling Fan

Frame Size	Series	MODEL	Bearing	Voltage	Current	Speed	Air Flow	Pressure	Noise
Frame Size	Series	MODEL	Bearing	(V)	(A)	(RPM)	(CFM)	^{(IN H}2^O)	(dB-A)
60x60x20	6020	AG06012DB207300	BALL	12	0.1	4000	19.728	0.164	35.1
		AG06012LB207300	BALL	12	0.12	4500	21.419	0.203	36.6
		AG06012MB207300	BALL	12	0.15	5000	23.792	0.248	39
		AG06012HB207300	BALL	12	0.21	5500	27.67	0.306	42.1
		AG06012UB207300	BALL	12	0.24	6000	28.614	0.36	43.5
		AG06024DB207300	BALL	24	0.06	4000	19.728	0.164	35.1
		AG06024LB207300	BALL	24	0.07	4500	21.419	0.203	36.6
		AG06024MB207300	BALL	24	0.08	5000	23.792	0.248	39
		AG06024HB207300	BALL	24	0.12	5500	27.67	0.306	42.1
		AG06024UB207300	BALL	24	0.1	6000	28.614	0.36	43.5
		AG06012DX207600	HYPRO	12	0.1	4000	19.728	0.164	35.1
		AG06012LX207600	HYPRO	12	0.12	4500	21.419	0.203	36.6
		AG06012MX207600	HYPRO	12	0.14	5000	23.792	0.248	39
		AG06012HX207600	HYPRO	12	0.21	5500	27.67	0.306	42.1
		AG06012UX207600	HYPRO	12	0.24	6000	28.614	0.36	43.5

The above list is the standard model, if you have special specification requirements, please contact our sales staff
